High Speed House Device Motor
Classification: Single-phase capacitor asynchronous motor
Application：Washing machine, Electric fan，Pump, Tools. Etc
Notes: The motors can be designed according to customer requirements
High Speed House Device Motor
Teamwork Global Group's YY series induction motors are widely used in House Device products. At the same time, it has the advantages of high speed, low noise, and long life, so most families will have this motor in fans, washing machines, etc. At the same time, it is also the first choice of many home appliance manufacturers. Because it will bring a happy experience to every family that uses it.
1. Product Introduction
We provide good quality 220V 50HZ induction motor China sample test. YY series single-phase capacitor running asynchronous motor have good performance, safe and reliable operation, nice appearance, convenient maintenance low noise, slight vibration, light weight and simple construction.We are also supply gear motors.
2. Product Parameter
|
Type |
Power |
Current |
Speed |
Eff |
Power Factor |
Starting current/Rated current |
Starting torque/Rated torque |
Max torque/Rated torque |
|
|
Hp |
kW |
(A) |
(r/min) |
(%) |
(cos￠) |
||||
|
220V 50HZ 2P |
|||||||||
|
YY6312 |
1/6 |
0.12 |
0.99 |
2800 |
60 |
0.92 |
3.5 |
0.5 |
1.7 |
|
YY6322 |
1/4 |
0.18 |
1.4 |
2800 |
65 |
0.92 |
5 |
0.4 |
1.7 |
|
YY7112 |
1/3 |
0.25 |
1.9 |
2800 |
66 |
0.92 |
7 |
0.4 |
1.7 |
|
YY7122 |
1/2 |
0.37 |
2.7 |
2800 |
67 |
0.92 |
10 |
0.35 |
1.7 |
|
…… |
… |
… |
… |
… |
… |
… |
… |
… |
… |
Please refer to the attachments for more details
3. Product Feature And Application
This small motor is suitable for household appliances (washing machine, electric fan,pump), electric tools ( hand electric drill) and all kinds of light loading and none loading start equipment.
4. Production Details
The motors can be designed according to customer's requirements
Custom design: Welcome
5. Product Qualification
Certificate: CCC.ROHS.CE.UL.Etc
6. Deliver, Shipping And Serving
MOQ: 50pcs.according to unit price and customer request
Packing: Good quality exporting packing style
Loading port: Any port in China
Transportation: By air or vessel, according to customer request
Payment terms: 30% T/T deposit, 70%T/T before shipment or Full L/C at sight
7. FAQ
Q: What certifications do you have?
A: We have 3C, CE, TUV & VDE, NF, UC & FCC, UL, SASO, ROHS.
Q: When can I get the quotation?
A: We usually quote within 24 hours after we get your inquiry. If you are urgent to get the price, please send the message on trade management.
Q: How can I get a sample to check the quality of your products?
A: After price confirmed, you can require for samples to check quality.
Q: Can you do OEM for us?
A: Yes, the product packing can be designed as you want, but the MOQ for each item is 50 sets.
8. About us
Our production and equipment
my phone number:+86 17793405349
20
years
We have been working in the industry since 1988
32
certificates
We have obtained most of the professional certificates in the industry and insist on international standards of production.
18
awards
We have won a lot of awards for strong creativity
