The difference between stepper motor bus control and pulse control
The stepping motor controls the speed, position and direction by receiving the pulse current. The number of pulses determines the position of the stepping motor. The rate of the pulse determines the speed of the motor. The direction of the pulse determines the steering of the motor. Most of the stepper motor control methods now use plc to pulse the driver, and the driver drives the motor to run. The pulse type method has existed for several decades. For some applications, the pulse type can not meet the demand, and the bus type is needed for control.
For those situations where many motors are needed, for example, many medical devices have twenty or thirty axes. If the pulse type is not well controlled, one plc can control six or seven axes at most, and multiple motors require multiple upper positions. Machines, space requirements are relatively large, and most medical devices are relatively small and compact. Second, the motor has more pulse-type wiring, and there are signal interference problems that cause equipment instability. If you use the bus type, you only need two signal lines and power lines to connect all the motors in series. It is very convenient to design and install, and there is no signal interference problem of a large number of wiring.
Some machines have a computer host on their own. If you use a pulse type, you can't use the host computer. You also need a host computer or motion control card to control the stepper motor drive system. You can use the bus type directly from the computer. Control, professional performance with motion control card, and cost and space volume are also superior to the other two.
Some products require a torque mode during the movement. For example, the lock screw machine uses a torque mode. The pulse type cannot control the motor current to adjust the torque, and the bus type can do it.
Compared with the pulse type, the bus type is not only small in size, but also the programming of the control program is much simpler than the plc ladder program. It can also make the current feedback of the motor current, voltage, temperature, stall, etc., current, Simple change of subdivision, simple control of s-shaped acceleration/deceleration, analog quantity, synchronization command, offline control, etc. In general, the bus type has many new features for the pulse type and has no disadvantages. The bus type is the development direction and trend of the motion control of the stepping motor in the future.
