When installing a miniature DC geared motor, it is necessary to install the correct installation steps and methods to ensure the normal operation of the miniature geared motor equipment. Therefore, before installing the geared motor, be sure to understand the installation method of the miniature geared motor.
The installation method of micro gear motor:
1. Before installation, confirm whether the motor and the reducer are in good condition, and strictly check whether the dimensions of the parts connected with the motor and the reducer match. Here are the dimensions and matching tolerances of the positioning boss of the motor, the input shaft and the groove of the reducer.
2. Unscrew the screw on the dust-proof hole on the outer side of the reducer flange, adjust the PCS system clamping ring so that the side hole is aligned with the dust-proof hole, insert the inner hexagon and tighten. After that, remove the motor shaft key.
3. Connect the motor and the reducer naturally. When connecting, it must be ensured that the concentricity of the output shaft of the reducer and the input shaft of the motor are consistent, and the outer flanges of the two are parallel.
Before connecting the motor and the reducer, the keyway of the motor shaft should be perpendicular to the tightening bolt.
Definition of micro gear motor:
Micro geared motor DC governor is a device for adjusting the speed of a DC motor. Since a DC motor has the characteristics of low speed and high torque, it cannot be replaced by an AC motor. Therefore, the device that adjusts the speed of a DC motor, the DC governor, has a wide range of applications. world.
The principle of micro gear motor:
A miniature DC gear motor is a device that adjusts the speed of a DC motor. The upper end is connected to the AC power supply, and the lower end is connected to the DC motor. The DC speed governor converts the AC power into two output DC power sources, and one input is to the DC motor (recommended: DC geared motor) Magnetization (stator), one input to the armature (rotor) of the DC motor, and the DC governor adjusts the speed of the DC motor by controlling the DC voltage of the armature.
At the same time, the DC motor gives a feedback current to the governor, and the governor judges the speed of the DC motor according to the feedback current, and corrects the armature voltage output if necessary, so as to adjust the speed of the motor again. The above is the summary of what to pay attention to when installing a miniature geared motor. I hope it can help you. If you have any questions or needs, please contact us, and we will provide you with stable and reliable products.
Micro DC geared motor is also a kind of motor, but it is more stable than ordinary motor. This motor is widely used and has applications in various industries. When we use the device, we do not use it casually. This also has certain requirements, and it can be used only when the conditions are met. So let's take a look at the conditions for the use of this motor.
1. The installation environment must be dry and well ventilated. The ambient temperature is between -5°C and 40°C, and special attention should be paid to abnormally high or low temperatures.
2. Do not use miniature DC geared motors in explosive environments, flammable oxygen environments, corrosive environments and water leaking environments.
3. Do not forcibly bend, pull or clamp the power supply, cables and motor wires.
4. After the motor is installed, it is necessary to use the grounding wire for good grounding, and the position of the grounding wire is on the junction box.
5. Installation, connection, inspection, etc. must be carried out by professional and technical personnel.
6. The gear reduction motor needs to be installed on a flat and solid base.
The above is about the installation and use conditions of the micro DC gear motor. When using the micro DC motor, we must check the surrounding environment according to the requirements we introduced above. We can only work better if the geared motor has been properly handled for environmental problems, especially for the temperature requirements, it must not exceed 40 °C to avoid explosive events.
