Big Torque Cleanner Motor
Classification：Universal Motor
Application：Vacuum Cleaner
Notes: The motors can be designed according to customer requirements
A Big Torque motor is a motor capable of providing high torque output. It is usually used in applications with high load, high rotational speed, or high power requirements, such as agriculture, industry, transmission, transportation, and construction. The following is a complete overview of the large torque motor, including the application scenarios and working principles.
Application:
Big Torque motors can be applied in many fields, such as:
1. Industry and manufacturing: for robots, drives in factory lines and other high-load equipment.
2. Construction and transmission: drives for large machinery, transmission towers, etc.
3. Transportation: the drive device used for logistics equipment, railway vehicles, mining vehicles, etc.
These seem to be in the need for strong transmission operations, will have the need for the use of a Big Torque motor, only the large torque motor can safely complete these tasks.
Operational Principle:
The working principle of a Big Torque motor depends on its internal structure and physical properties. They include:
1. Electromagnetic field: When a current is transmitted to the winding of the motor, a magnetic field is generated. This magnetic field will interact with the motor's magnet to create a torque.
2. Induction: When the motor is in a rotating state, it will produce an electric eddy current between the rotor and the stator, resulting in a reverse torque. This torque is also known as the electromagnetic drag power.
3. Magnet: The motor includes two types of magnets, namely, stator and rotor magnets. These magnets create an interaction between the current and the induction to generate a torque.
There are many types of Big Torque motors, such as DC motor, AC motor and synchronous motor. Each type of motor has unique characteristics and usage scenarios. When selecting the motor method, the appropriate type and model should be selected according to the specific work requirements.
To sum up, the Big Torque motor is an indispensable driving device in modern industry and production. They can achieve high load, high torque, high efficiency and reliability through many types of motors. Therefore, when selecting the motors, the suitable type and model should be selected according to the work requirements.
1.Product Introduction
The motor of a high pressure cleaning machine comprises a first housing, each end of which is provided with a holding chamber;The second housing is arranged opposite to one of the holding Chambers in the first housing and is fixed by threaded fasteners as an installation space for the power assembly;The other chamber of the first housing is used as the installation space of the pressure pump to realize the integrated installation of the motor and the pressure pump.
2. Product Parameter
Specification | Model | TW-139 | TW-139 | Tolerance Value |
Voltage(V) | 220 230 240 100 110 120 | 220 230 240 100 110 120 | / | |
Frequency(Hz) | 50/60 | 50/60 | / | |
Input (W) | 1000 | 1200 | ±10% | |
Max Vacuum Degree(KPa) | 19 | 20 | -5% | |
Max Air Quantity(m3/min) | 3 | 3.1 | -8% | |
Temp. Rise(K) | <85 | <85 | / | |
Noisy(dB) | 96 | 98 | / | |
Sparkle Grade | <2 Level | <2 Level | / | |
Insulation Grade | B | B | / | |
Max Eff.(%) | 35 | 35 | -10% |
Specification | Model | TW-107 | TW-107 | Tolerance Value |
Voltage(V) | 220 230 240 100 110 120 | 220 230 240 100 110 120 | / | |
Frequency(Hz) | 50/60 | 50/60 | / | |
Input (W) | 800 | 1000 | ±10% | |
Max Vacuum Degree(KPa) | 20 | 22 | -5% | |
Max Air Quantity(m3/min) | 2.3 | 2.4 | -8% | |
Temp. Rise(K) | <85 | <85 | / | |
Noisy(dB) | 92 | 94 | / | |
Sparkle Grade | <2 Level | <2 Level | / | |
Insulation Grade | B | B | / | |
Max Eff.(%) | 36 | 36 | -10% |
3. Product Feature And Application
Typical Application Examples: vacuum cleaner motor
Characteristics: High speed, long service life, high torque
4. Production Details
The motor size and motor material can be designed by request
Custom design: Welcome
5. Product Qualification
Certificate: CCC.ROHS. CE. UL. Etc
According to customer requirement
6.Deliver, Shipping And Serving
Loading port: Any port in China
Packing: Good quality exporting packing style
Transportation: By air or vessel, according to customer request
Sample lead time: 7-15 days
7.FAQ
Q: Are you a trade company or a manufacturer?
A: We are an ISO, SGS, CE, CCC, Alibaba approved manufacturer specialized in motors for home/hotel/supermarket appliance, including AC Motors, Series Motors, DC motors, brushless motors and induction motors. The motors applied in wet & dry utility, vacuum cleaners, mini vacuum cleaners, industrial vacuum, carpet extractor, spa bath pumps, juicers, blenders, food processors, coffee makers, ice crusher, shaver, sewing machines, line cutting machines, gym equipment and electric hand dryers etc.
Q: What is your delivery date?
A: The delivery date is about 25-30 days after receipt of payment.
Q: What is the most important advantage for the export?
A: Besides the competitive price with the good quality, the critical point is the quick response the efficient export team and the fast delivery time.
Q: Do you offer OEM service?
A: Yes. We accept OEM service.
