Power Tool Motor
Classification：Micro DC Motor
Application：Garden tools, Printer, Drill, Screw driver. Etc
Notes: The motors can be designed according to customer requirements
Power Tool Motor
A power tool motor is a device that provides current through a power source and converts electrical energy into mechanical energy. Its working principle is to use the interaction of electromagnetic induction and current to act on the magnetic field to generate rotational torque, thereby driving cutting, striking, polishing and other work. After continuous improvement and upgrading, power tool motors have become highly efficient, safe, energy-saving, and environmentally friendly. They are widely used in home decoration, construction, machinery manufacturing and other fields, greatly improving production efficiency and working conditions. We should actively learn the knowledge of power tool motors, use power tools correctly, and improve work efficiency and production quality.
1.Product Introduction
WeChat DC motor 775 is a common DC motor that is widely used in mechanical equipment. Its working principle is mainly to provide DC power to the motor through the power supply, and then the rotor is subjected to electromagnetic induction force, forming a rotational torque, thereby promoting the normal operation of the equipment. This kind of motor is made of high-quality materials and has the characteristics of high stability, long life and low noise. It is widely welcomed by users due to its efficient working performance. WeChat DC Motor 775 gives people a feeling of innovation, stability and efficiency, and has important application value and economic benefits.
2. Product Parameter
Model | Voltage | At No Load | At Max Efficiency | Stall | ||||||
Volt range | Rated volt | RPM | A | RPM | A | G.CM | W | % | G.CM | |
TW-775PM-2765 | 6～30.0V | 24.0V Constant | 7600 | 0.37 | 5810 | 2.22 | 750 | 44.7 | 83.0 | 3186 |
TW-775PM-27100 | 6～30.0V | 24.0V Constant | 4264 | 0.26 | 3479 | 1.25 | 530 | 18.9 | 63.0 | 2892 |
TW-775PM-3848 | 6～30.0V | 24.0V Constant | 8600 | 0.55 | 7310 | 3.33 | 750 | 56.3 | 70.4 | 5000 |
TW-775PM-4040 | 6～15.0V | 12.0V Constant | 5000 | 0.55 | 4199 | 2.94 | 460 | 19.8 | 56.1 | 2880 |
TW-775PM-4045 | 6～15.0V | 12.0V Constant | 4600 | 0.60 | 3500 | 4.30 | 860 | 36.6 | 70.9 | 3600 |
TW-775PM-5026 | 6～12.0V | 12.0V Constant | 8300 | 1.00 | 7050 | 5.68 | 650 | 47.0 | 69.0 | 4318 |
TW-775PM-5036 | 6～12.0V | 12.0V Constant | 6000 | 0.70 | 4800 | 4.86 | 800 | 40.0 | 68.6 | 4000 |
TW-775PM-7513 | 6～12.0V | 12.0V Constant | 18700 | 2.20 | 16000 | 13.60 | 710 | 116.5 | 71.4 | 5100 |
3. Product Feature
1. High efficiency: Compared with traditional hand tools, electric tool motors have higher power and speed, which can complete work tasks faster and improve work efficiency.
2. Safe and reliable: The electric tool motor adopts a fully enclosed structure, which can effectively prevent sparks and arcs generated inside the motor and ensure the safety of workers.
3. High stability: The control system of the electric tool motor adopts an intelligent design, which can accurately control the voltage, current, speed and other parameters of the motor to ensure stable work.
4. Simple maintenance: The housing of the power tool motor is made of high-strength material, which is not easily damaged or deformed, has simple maintenance and has a long service life.
5. Wide scope of application: Power tool motors come in various specifications and models, and can be applied to the processing and processing of different materials in different fields.
4.Application
Typical Application：Cordless Power Tools : Drills & Screwdrivers
Office Automation Equipments: Printer / Cordless Garden Tools
Characteristics: High efficiency, Low noise, long service life
5. Production Details
