Lawn mower, also known as lawn machine, is composed of cutter head, engine, walking wheel, walking mechanism, blade, handrail and control part. It is composed of parallel four-bar lifting device, frame, left and right single wing weeding device, the whole machine deviation adjustment device, comb tooth rotating bevel gear increasing transmission mechanism and comb tooth copying depth adjustment device. The efficiency is 8 to 10 times higher than that of artificial weeding, and the seedling damage rate is low, and the cleaning rate of seedling removal is high.
(1) Weeding device
Weeding width: 900mm
Drive mode: V-belt
Maximum operating radius: 3.7m
(2) hydraulic power plant
The hydraulic quick joint at the front end of the vehicle leads to the power, drives the weeder device, and controls the left/right, up/down and other actions of the mechanical arm.
Weeding device: hydraulic motor; Hydraulic cylinder of manipulator; Single fuel saving cylinder; Double fuel saving cylinder; Anti-impact cylinder; Weeder Angle adjustment cylinder; Support cylinder
(3) Manipulator system
The weeding device is installed at the end of the mechanical arm. There are 2 mechanical arms, which can adjust various angles freely.
Shape: quadrangular arms
Weeding machine
Lawn mower (1 sheet)
Material: high strength steel plate
(4) Control system
The left/right, up/down actions of the weeding device and the mechanical arm are operated by a single person from the control panel of the cab.
Its characteristics are flat work, simple operation, for the need to cut objects, mainly grass cutting strong, suitable for high-yield grasslands and large parks, etc. Lawnmower cuts grass by the relative cutting motion of moving knife and fixed knife on the cutter. It is characterized by neat stubble, low power required, poor adaptability to herbage and easy blockage, so it is suitable for the operation of flat natural grassland and artificial grassland. Rotary mowers were manufactured and used in the mid-1980s. Cutting grass by impact with a blade on a high-speed rotating cutter head. With the improvement of science and technology, the work ability of the new and improved lawn mower products is enhanced a lot, and the speed is improved a lot, which saves the working time of the weeding workers and saves a lot of human resources.
