Modern Vacuum Cleaner Motor
Classification：Universal Motor
Application：Vacuum Cleaner
Notes: The motors can be designed according to customer requirements
Our company specializes in exporting electric motor. We can supply a wide range of products to meet ever-changing market demands. Selling well throughout the domestic market, our products are also warmly welcomed by clients in European countries.
1. Product Introduction of the AC universal motor
We are a professional enterprise engaged in the manufacture and sale of electric motor. We also supply induction motor and so on. We believe that quality is the soul of an enterprise.
2. Product Parameter of the AC universal motor
Specification | Model | TW-145 | TW-145 | Tolerance Value |
Voltage(V) | 220 230 240 100 110 120 | 220 230 240 100 110 120 | / | |
Frequency(Hz) | 50/60 | 50/60 | / | |
Input (W) | 1100 | 1200 | ±10% | |
Max Vacuum Degree(KPa) | 18 | 19 | -5% | |
Max Air Quantity(m3/min) | 3.1 | 3.2 | -8% | |
Temp.Rise(K) | <85 | <85 | / | |
Noisy(dB) | 98 | 100 | / | |
Sparkle Grade | <2 Level | <2 Level | / | |
Insulation Grade | B | B | / | |
Max Eff.(%) | 33 | 33 | -10% |
Specification | Model | TW-146 | TW-146 | Tolerance Value |
Voltage(V) | 220 230 240 100 110 120 | 220 230 240 100 110 120 | / | |
Frequency(Hz) | 50/60 | 50/60 | / | |
Input (W) | 1200 | 1400 | ±10% | |
Max Vacuum Degree(KPa) | 22 | 23 | -5% | |
Max Air Quantity(m3/min) | 3.1 | 3.15 | -8% | |
Temp.Rise(K) | <85 | <85 | / | |
Noisy(dB) | 96 | 98 | / | |
Sparkle Grade | <2 Level | <2 Level | / | |
Insulation Grade | F | F | / | |
Max Eff.(%) | 35 | 35 | -10% |
3. Product Feature And Application of the AC universal motor
Modern Vacuum Cleaner Motor is the heart of vacuum cleaner, the main types of vacuum cleaner motor are: dry vacuum cleaner motor (THRU FLOW), dry and wet vacuum cleaner motor (BY-PASS). Vacuum cleaner motor is composed of two parts: the motor part and the fan part, because the vacuum cleaner motor on the speed is very high, generally in 20,000-30000 revolution per minute, so the motor is mainly used in series motor, also known as series motor.There are copper motor and aluminum motor.
Copper wire motor has the advantages of high temperature resistance, long life, long single operation time, but the price is higher than aluminum wire;
Aluminum wire motor has the characteristics of low price, but poor temperature resistance, low melting point, life is not as long as copper wire.Series motor is mainly composed of stator, rotor, front and rear end cover (cover) and cooling blades. The stator consists of a stator core and a winding on the pole shoe, which is used to generate excitation flux, magnetic conductivity and support the front and rear covers. The rotor is composed of rotor iron core, shaft, armature winding and commutator, whose function is to ensure and generate continuous electromagnetic torque, and to convert electrical energy into mechanical energy by driving the load to do work through the rotating shaft. The front and rear cover supports the armature, connecting and fixing the rotor into one. Among them, the rotating shaft, front and back cover should have enough strength to prevent the armature and cover resonance phenomenon, cause vibration and danger. Generally, there are rolling or sliding bearings in the front and back cover.
4. Production Details of the AC universal motor
The stator field winding and the armature (rotor) winding are in series, which can pass both DC and AC. The motor has a commutator.The motor has the characteristics of high temperature resistance and long life time.
The motor size and motor material can be designed by request
Custom design: Welcome
5. Product Qualification of the AC universal motor
Certificate: CCC.ROHS. CE. UL. Etc
According to customer requirement
6.Deliver, Shipping And Serving of the AC universal motor
Production lead time: 15-40 days after receipt of approval samples and receipts
Loading port: Any port in China
Packing: Good quality exporting packing style
Payment terms: 30% T/T deposit, 70%T/T before shipment or Full L/C at sight
7.FAQ
Q: In what areas is your company's products mainly used?
A: The products are widely used in the fields of machinery industry, chemical industry, power industry, steel industry, water conservancy engineering, metallurgy, mining and cement.
Q: What's the deliverly time of sample and the cargo?
A:For regular specification, it needs about 3-5 working days for samples, and 15-20 working days for the cargo; For customized specification, it needs about 7-10 working days for samples, 25-30 working days for the cargo.
Q: How long is the Delivery?
A: Delivery time depends on the quantity you order. Usually it takes 15-25 working days.
Q: Which shipping way is available?
A: Sample and small order by DHL, UPS, FedEx, TNT, EMS, China Post more fast but expensive Bulk order by air or by sea cheap but slow.
Q:Is there a MOQ for your motors?
A:Yes. The MOQ is between 1000~10,000pcs for different models after sample approval. But it's also okay for us to accept smaller lots like a few dozens, hundreds or thousands for the initial 3 orders after sample approval. for samples, there is no MOQ requirement. But the less the better (like no more than 5pcs) on condition that the quantity is enough in case any changes needed after initial testing.
